(1), The power adopts Loncin Petrol engine, oil-electric hybrid power, with its own
power generation and power supply
system, automatic charging in the working process.
(2), The motor adopts Japanese imported DC brushless motor, energy-saving and durable,
suitable for long time work.
(3), Automatic brake for stopping, suitable for steep slope operation.
(4), The generator is a marine-grade generator with very low failure rate and long
life.
(5), The control chip is imported, industrial remote control device, simple operation,
low failure rate, remote control
distance greater than or equal to 200 meters.
(6), Crawler adopts internal steel frame steel wire, external engineering rubber design,
wear-resistant and durable.
(7), Strengthen the chassis, low body, tank type design, climbing over the ditch is a
strong point; especially suitable
for: dams, orchards, hills, terraces, photovoltaic power generation, and green
mowing.
(8), Adjustment: leave grass height 2 to 15 centimeters adjustable, mowing speed remote
control adjustable.
Several remote controls are available for purchase.
A dosing unit, transport pallet, snow shovel, and lifting platform can be purchased
separately and mounted on the lawn
mower.
Users can purchase the GPS positioning and navigation function, Fully unmanned
autonomous driving system.
(1), Support BeiDou and other multi-frequency satellite positioning system, using RTK
positioning technology.
(2), Positioning and travelling accuracy can reach ±2cm, high precision operation is
guaranteed.
(3), support for autonomous routing, planning, decision-making and walking control
algorithms.
(4), millisecond-level multiple sensors, easy to achieve intelligent perception.
Multiple sensors are guaranteed, such as rotational speed sensor, oil level sensor,
travelling sensor, temperature
sensor, etc.
Support 4G network or digital transmission radio, remote control, automatic start and
stop, intelligent and safer.
Ultra-high definition camera, automatic obstacle avoidance.
In the case of multiple mowing robots, free base station can be built to support
multi-machine clustering.
| main unit | Model | KT80 |
| Machine Size(LxWxD) | 1140x1140x620 mm | |
| Weight | 280 kg | |
| Crawler width | 120 mm | |
| Fuel tank capacity | 6 L | |
| Power generation function |
manufacturer | Loncin |
| Model | LC1P92F-1 | |
| Type | Single cylinder, Four-stroke, Air cooling |
|
| Max.Power | 16 Ps | |
| Rated speed | 3600 r/min | |
| Fuel label | Petrol | |
| Average oil consumption | 1.5 to 2 L/h | |
| Displacement capacity | 452 cc | |
| Motor | place of origin | Japan |
| Rated power | 1000x2 w | |
| Working Voltage | 48 V | |
| Rotation speed | 1000 to 3000 r/min | |
| Walking speed | 0 to 5 km/h, adjustable | |
| Remote Control Distance | ≥200 m | |
| Working slope | ≤50 degree | |
| Power generator | Rated power | 5 kw |
| Batteries | type | dry storage battery |
| Remote Battery Voltage | V | |
| Walking battery voltage | 48 V | |
| Traveling Battery Capacity | 80 Ah | |
| Charging type | Automatic charging during generator operation |
|
| Lawn mowing knives | Number of cutters | 2 pieces |
| Cutter Rotation Speed | 2500 to 3000 r/min | |
| Mowing width | 800 mm | |
| Grass retention height | 20 to 150 mm, adjustable |
| Channel Quantity | 8 | Working Voltage | 4.2 to 9V |
| Frequency | 2401to 2478 MHz | Frequency Hopping | S-FHSS |
| Weight | 550 g | Size | 180x85x185mm |
| Power Supply | 4x5 batteries or 2S lithium batteries | ||
| Receiver | |||
| Working Voltage | 4.5 to 6V | Support | MC9002(standard), can also MC8RE, MC7RB, MC6RE, E6R-E, M-BUS |
